Software | |
Switching | Support port configuration, such as port rate, duplex mode, flow control, jumbo frame, etc Support 802.1Q VLAN, port/MAC/subnet/protocol based VLAN division, GVRP, port isolation Support port speed limit, storm suppression, storm detection, static port convergence, dynamic convergence LACP Support MAC address aging, static MAC address binding and filtering, and MAC address learning restrictions |
Redundancy | Support MW-RingV2 private ring network technology support EAPS support ERPS Support STP/RSTP/MSTP |
Broadcast | Support IGMPv1/v2/v3, and IGMP Snooping Support the static multicast GMRP Support PIM-DM, PIM-SM |
Routing | Support static routing Support RIPv1/v2, OSPF dynamic routing support VRRP |
Security Management | Support ring circuit detection Support HTTP, HTTPS, TELNET, and SSH access mode Support ACL and filtering data on the L2-L4 layer Support 802.1X port authentication and MAC address authentication Support dual power redundancy drop relay alarm |
Management and Maintenance | Support for QoS quality of service, Cos / DSCP / Policy mapping, and WRR / SP / SRR queue scheduling algorithm Support for DHCP Server / Security / Relay / Snooping Support SNMP v1 / v2c / v3, SNMPv1 / v2c Trap, LLDP Support port mirror, Ping, Tracert Support user rights management, system logs, local time setting synchronization, and SNTP network time synchronization Support online restart, restore factory Settings, system upgrade, configuration file upload / download Support for unified upper-level computer software management |
Switch Capability | |
Processing Mode | Store and forward |
Backplane Bandwidth | 128G |
Buffer Size | 12Mbit |
MAC Table Size | 16K |
Interface | |
10G Fiber Port | 4*10GBase-R SFP+ ports, support 1000Base-X |
1G Copper Port | 8*10/100/1000Base-T(X) auto-sensing RJ45 ports, full/half duplex, auto MDI/MDI-X connection |
100M Fiber Port | 16*100Base-FX fiber port, support SC/FC/ST connector, multimode/single mode optional |
Relay | 1 relay alarm output, 3-pin 5.08mm terminal block |
CONSOLE | 1 RJ45 CONSOLE port of RS232 signal for equipment debugging and command line configuration |
Status LED | Power indicator, operation indicator, alarm indicator, interface rate and connection / active status indicator |
Power Supply | |
Input Voltage | AC85~264V/DC110~370V Dual power redundancy |
Power Consumption | ＜29W@AC220V (full load) |
Connection | 5-pin 5.08mm terminal block |
Protection | Over current protection |
Physical Characteristics | |
Dimension | 482.6×44×315 mm (Including mounting brackets) |
Installation | |
