Software

Switching

Support 802.1Q VLAN, VLAN/IP subnetwork/protocol- based VLAN, VLAN translation, and PVLAN

Support port aggregation, static aggregation, dynamic aggregation LACP

Support MAC address aging and learning restrictions, static unicast or multicast MAC address binding

Support ports configuration, such as port rate, duplex mode, flow control, maximum frame length, etc

Support port statistics

Redundancy

Support ERPSv1/v2

Support STP/RSTP/MSTP

Broadcast

Support IGMP snooping

Support multicast filtering

Routing

Support IPv4/IPv6 static routing

Support for RIPv1/v2, OSPF dynamic routing

Security Management

Support ports security and loopbacks detection

Support HTTP, HTTPS, TELNET, and SSH access control

Support 802.1 port authentication, AAA authentication, RADIUS, TACACS + protocol

Support for source IPv4/IPv6 protection and ARP protection

Management and Maintenance

Support DHCPv4/v6 Client, DHCPv4 Server/Snooping / Relay

Support SNMPv1/v2c/v3, SNMP Trap, RMON, LLDP

Support port mirroring, DDM, Ping IPv4/IPv6, and Traceroute IPv4 / IPv6

Support user rights management, log, NTP client, daylight saving time

Support profile upload/download/activation / deletion, mirror double backup, restart, and restore factory settings

Switching

Processing Type

Store-and-forward

Backplane Bandwidth

180G

Cache size

32Mbit

MAC Table Size

32K

Interface

10G Fiber Port

4*10GBase-R SFP+ ports

1G Fiber Port

24*1000Base-X SFP ports

1G Copper Port

8*10/100/1000Base-T (X) auto-sensing RJ45 ports, full / half-duplex, auto MDI/MDI-X connection

Relay

1 relay alarm output, 3-pin 5.08mm terminal block

CONSOLE

1 RJ45 CONSOLE port of RS232 signal for equipment debugging and command line configuration

Status LED

Power indicator, operation indicator, alarm indicator, port indicator

Power Supply

Power Input

AD220V(AC85~264V/DC110~370V)

Power Consumption

＜50W@AD220V (full load)

Connection

5-pin 5.08mm terminal block

Protection

Over current protection

Physical Characteristics

Dimension

482.6×44×315 mm (Including mounting brackets)

Installation

Standard 19-inch 1U rack-type mount

IP Code

IP40
