开关

支持端口配置、端口限速、风暴抑制、风暴检测、静态端口聚合和 LACP

支持802.1Q VLAN，基于端口/MAC/子网/协议的VLAN划分，GVRP和端口隔离

支持MAC地址老化、静态MAC地址转发过滤、MAC地址绑定、学习限制

冗余

支持MW-RingV2专用环网技术

支持EAPS和ERPS

支持STP/RSTP/MSTP

组 播

支持IGMP监听

支持静态组播 GMRP

安全管理

支持HTTP、HTTPS、TELNET、SSH等访问方式

支持 ACL 在 L2-L4 层进行数据过滤

支持 802.1X 端口认证和 MAC 地址认证

支持环回检测和继电器报警

管理与维护

支持QoS， SNMP v1/v2c/v3， SNMP v1/v2c Traps， LLDP

支持端口镜像、Ping、Tracert

支持用户权限管理、系统日志、本地时间设置同步、SNTP网络时间同步

支持在线重启、恢复出厂、系统升级、配置文件上传/下载

支持统一的上层软件管理

开关能力

加工类型

存储和转发

背板带宽

128Gbps的

缓冲区大小

12M比特

MAC 表大小

8 千米

接口

10G光纤端口

4*10GBase-R SFP+接口，兼容1000Base-X

1G组合

8*千兆组合端口，支持10/100/1000Base-T（X）自动感应RJ45端口或1000Base-X SFP插槽可选。10/100/1000Base-T（X） 端口支持全/半双工和自动 MDI/MDI-X

1G 铜缆端口

16*10/100/1000Base-T（X） 自适应 RJ45 端口，支持全/半双工和自动 MDI/MDI-X

中继

1 个继电器报警输出，带 3 针连接器，间距为 5.08mm，并配有锁定机构

安慰

1 个带 RJ45 连接器的 CONSOLE 端口，支持 RS232 信号，用于设备调试和命令配置

状态指示灯

电源指示灯、操作指示灯、报警指示灯、接口速度和链路/活动状态指示灯

电源

输入电压

单或双AC85~264V/DC110~370V电源可选

功耗

<30W@AC220V（满载）

连接

5 针接线端子，间距为 5.08mm，带锁定机构

物理特性

尺寸

482.6×44×315（mm）（含安装支架）

装置

19英寸1U机架式

知识产权

IP40防护等级

重量

Software

Switching

Support port configuration, port speed limiting, storm suppression, storm detection, static port aggregation, and LACP

Support 802.1Q VLAN, VLAN division based on port/MAC/subnet/protocol, GVRP, and port isolation

Support MAC address aging, static MAC address forwarding and filtering, MAC address binding, and learning restrictions

Redundancy

Support MW-RingV2 private ring network technology

Support EAPS and ERPS

Support STP/RSTP/MSTP

Multicast

Supports IGMP snooping

Supports static multicast GMRP

Security Management

Support HTTP, HTTPS, TELNET, SSH access methods

Support ACL for data filtering at L2-L4 layers

Support 802.1X port authentication and MAC address authentication

Support loopback detection and relay alarm

Management and Maintenance

Support QoS, SNMP v1/v2c/v3, SNMP v1/v2c Traps, LLDP

Support port mirroring, Ping, Tracert

Support user privilege management, system logs, local time setting synchronization, and SNTP network time synchronization

Support online reboot, factory reset, system upgrade, configuration file upload/download

Support unified upper-level software management

Switch Capability

Processing Type

Store-and-Forward

Backplane Bandwidth

128Gbps

Buffer Size

12Mbit

MAC Table Size

8K

Interface

10G Fiber Port

4*10GBase-R SFP+ ports, compatible with 1000Base-X

1G Combo

8*Gigabit combo ports, support 10/100/1000Base-T(X) auto-sensing RJ45 ports or 1000Base-X SFP slots optional. 10/100/1000Base-T(X) ports support full/half duplex and auto MDI/MDI-X

1G Copper Port

16*10/100/1000Base-T(X) auto-sensing RJ45 ports, support full/half duplex and auto MDI/MDI-X

Relay

1 relay alarm output with 3-pin connectors spaced at 5.08mm and equipped with locking mechanisms

CONSOLE

1 CONSOLE port with a RJ45 connector, supporting RS232 signal for device debugging and command configuration

Status LED

Power indicator, Operation indicator, Alarm indicator, Interface speed, and Link/Activity status indicator

Power Supply

Input Voltage

Single or dual AC85~264V/DC110~370V power supply optional

Power Consumption

＜30W@AC220V(full load)

Connection

5-pin terminal block with a 5.08mm pitch and locking mechanism

Physical Characteristics

Dimensions

482.6×44×315(mm) (mounting brackets included)

Installations

19inch 1U Rack mount

IP Code

IP40

Weight
