Software

Switching

Support ports configuration, such as port rate, duplex mode, flow control, maximum transmission unit, etc

Support 802.1Q VLAN, port isolation

Support port speed limit, storm suppression, storm detection, static port convergence, dynamic convergence LACP

Support MAC address aging, static unicast MAC address binding

Redundancy

Support MW-Ring/MW-RingV2 private ring network technology

Support ERPSv1/v2

Support RSTP and compatible to STP

Broadcast

Support IGMP Snooping

Support static multicast MAC address binding

Security Management

Support WEB, TELENT, and SSH control

Support ACL and filtering data on the L2-L4 layer

Support 802.1X port authentication

Support the relay alarm, Email log

Support ring detection

Management and Maintenance

Support QoS, 802.1P/ DSCP / port priority mapping, absolute and versus priority control

Support SNMP v1/v2c/v3, SNMPv1/v2c/v3 Trap, RMON, LLDP

Support port mirroring, Ping

Support user rights management, system log, NTP client

Support online restart, factory reset, system upgrade, configuration file upload / download

Support unified upper computer software management

Switch Capability

Processing Type

Store-and-forward

Backplane Bandwidth

12.8Gbps

Cache Size

4.1Mbit

MAC Table Size

8K

Interface

Fiber Port

4/8/16*100Base-FX fiber ports optional, support SC/FC/ST connector, multi-mode/single mode

Copper Port

20/16/8*10/100Base-T (X) auto-sensing RJ45 ports optional, support full/half duplex mode, auto MDI / MDI-X connection

Relay

1*relay alarm output, 3-pin 5.08mm terminal block

CONSOLE

1*RJ45 CONSOLE port of RS232 signal for equipment debugging and command line configuration

Status LED

Power indicator, operation indicator, alarm indicator, interface rate and connection / activity indicator

Power Supply

Power Input

DC model: DC18~75V, dual power redundancy

AC model: AC 85~264V or DC110~370V, dual power redundancy

Power Consumption

＜16.5W@AC220V

Connection

5-pin 5.08mm terminal block

Protection

Over current protection

Physical Characteristics

Dimension

482.6×44×210mm (including mounting brackets)

Installation

Standard 19-inch 1U rack mount

IP Code

IP40

Weight

About 2.9kg
