Software

Switching

Support port configuration, port speed limit, storm suppression, storm detection, static port trunk, LACP

Support 802.1Q VLAN, port / MAC / subnet / protocol based VLAN division, GVRP, port isolation

Support MAC address aging, static MAC address binding and filtering, MAC address learning restrictions

Redundancy

Support MW-RingV2 private ring network technology

Support EAPS, ERPS

Support STP / RSTP / MSTP

Multicast

Support IGMPv1/v2/v3, and IGMP Snooping

Support the static multicast GMRP

Support PIM-DM, PIM-SM

Routing

Support static routing

Support RIPv1/ v2, OSPF dynamic routing

Support VRRP

Security Management

Support HTTP, HTTPS, TELNET, and SSH access mode

Support ACL and filtering data on the L2-L4 layer

Support 802.1X port authentication and MAC address authentication

Support ring detection, relay alarm

Management and Maintenance

Support DHCP Client/Server/Relay/Snooping

Support QoS, SNMP v1/v2c/v3, SNMPv1/v2c Trap, LLDP

Support port mirror, Ping, Tracert

Support user rights management, system logs, local time setting synchronization, and SNTP network time synchronization

Support online restart, factory reset, system upgrade, configuration file upload / download

Support unified upper-level computer software management

Switch Capability

Processing Type

Store-and-Forward

Backplane Bandwidth

54.8Gbps

Buffer Size

16Mbit

Mac Address Table

16K

Interface

1G Fiber Port

4*1000Base-X SFP ports

100M Fiber Port

16*100Base-FX, support SC/FC/ST, single mode/multimode, wavelength, transmission distance optional

100M Copper Port

8*10/100Base-T(X) auto-sensing RJ45 ports, support full/half duplex, auto MDI/MDI-X

Relay

1 relay alarm output, 5.08 mm pitch 3-pin terminal block

CONSOLE

1 CONSOLE port, RS232 signal RJ45 port, used for device debugging and command line configuration

Status LED

Power LED, operation LED, alarm LED, port rate and connection/activity LED

Power Supply

Power Input

Single/dual AC85~264V/DC110~370V

Power Consumption

＜35W@AC220V(full load)

Connection

5.08mm pitch 5-pin terminal block

Physical Characteristics

Dimension

482.6×44×315 mm (Including mounting brackets)

Installation

Standard 19-inch 1U rack-mounting
